8.5
Set-up guide — AKS 4100 280 mm
for ammonia heat pump application
Einrichtungsanleitung für AKS 4100 280 mm
Die Einrichtung und Kalibrierung des AKS 4100 280-mm-Füllstandsfühler darf nur von fachkundigem
Personal vorgenommen werden.
Die Anleitung liegt nur in englischer Sprache vor.
Warning!
Incorrect set-up may cause the compressor to break down.
The AKS 4100 contains
- A signal converter with HMI display and meta glass solution
- A process connection with probe
When the process connection with probe is properly installed in the system, the HMI display and signal
converter should be mounted on the process connection.
1
Fig. 27
Betriebshandbuch – ChillPAC und LP ChillPAC Mk 3
010823 de 2021.06
2
59/68
