4 Mounting
4.2.3

Panel cut-outs

Panel cut-outs according to DIN IEC 61554
Type
701080
701081
16
Panel cut-out
(width x height)
69 +1 mm × 28.5 +1 mm
Mounting depth Minimum spacing of panel
without seal cut-outs (for close mounting)
With terminal blocks Horizontal
62 mm 15 mm
72 mm
Vertical
30 mm
