4. Put the guard (6) on the grinding head.
5. Put the pressure plate (c) over the guard
and align it to the mounting holes in the
grinding head.
6. Adjust the guard so that the unprotected
part of the disc is as far away from the
hand holding the handle (4) as possible.
7. Tighten the three screws (b) so that the
guard sits firmly in place and cannot
move.
FIG. 4
REPLACING GRINDING DISC
WARNING!
• The disc can be very hot after use!
• Switch off the product, pull out the plug
and wait until the motor and spindle (c)
have completely stopped before pressing
the spindle lock button. The spindle lock
button must be held pressed when
replacing the disc.
1. Pull out the plug.
2. Hold the spindle lock button (2) pressed
to lock the spindle (c).
3. Turn the spindle until it locks.
FIG. 5
4. Remove the outer flange (a) and the
support plate (b) with the supplied flange
key.
5. Put the disc on the spindle.
6. Replace the disc support plate and the
outer flange.
7. Release the spindle lock button.
FIG. 6
Check the following before pressing the power
switch (4), that:
• The mains voltage corresponds to the
rated voltage on the type plate.
• The disc is correctly in place.
• The outer flange is firmly tightened.
• The disc rotates freely and smoothly.
GRINDING DISC WITH FLAT OR
COUNTERSUNK CENTRE
Screw the side handle into the hole on the side
of the gear housing, on the side preferred by
the user.
1. Disc support plate
2. Outer flange
FIG. 7
USE
• Keep a firm grip on the handle (4) and
support handle (5) when in use.
• Make sure not to put your hand over the
ventilation openings on the product, this
can cause the product to overheat. Wait
until the disc has reached maximum speed.
• For best results, hold the grinding disc at
an angle of 15-30° to the workpiece.
Move the tool smoothly backwards and
forwards, without pressing too hard. This
prevents ridging and overheating or
discolouring of the workpiece.
• Always check that the tool, the guard and
the grinding disc are in good condition
before use. When the disc comes into
contact with the workpiece this produces
a lot of sparks. The guard must be
positioned so that hot sparks are directed
away from the user.
• Run the angle grinder at a suitable speed
for the accessory in use.
FIG. 8
NOTE:
• Do not block the openings on the angle
grinder – risk of overheating and
material damage.
• Switch off the product after use.
