CHECKLIST

Hardware Step 1
#136. 3/8" × 2T_
Spring Washer (4 pcs)
#111. M5 × 10m/m
Phillips Head Screw (4 pcs)
#109. 3/8" × 3/4"_
Socket Head Cap Bolt (4 pcs)
Hardware Step 2
#120. 5/16" × 7T_
Nyloc Nut (6 pcs)
#114. Ø3.5 × 12m/m_
Sheet Metal Screw (4 pcs)
#133. 3/8" × 19 × 1.5T_
Flat Washer (4 pcs)
#114. Ø3.5 × 12m/m_
Sheet Metal Screw (2 pcs)
#135. 5/16" × 19 × 1.5T_
Curved Washer (4 pcs)
#101.
5/16" × 1-3/4"_
(6 pcs)
Hex Head Bolt
33
#132. Ø8.5 × 26 × 2.0T_
Flat Washer (2 pcs)
#99. 5/16" × 15m/m_
Hex Head Bolt (2 pcs)
#111. M5 × 10m/m
Phillips Head Screw
(10 pcs)
#84. Switch Wire Cap
(2 pcs)
