e) Sound-to-Light Mode

• Use the MENU (1) button to select SoUn in the menu and push the ENTER (4) button.
• Select the desired operating mode with the UP (3) and DOWN (2) buttons.
oFF Sound-to-light mode deactivated
on Sound-to-light mode activated
• Press the ENTER button (4) to confirm your selection.
The device is controlled via the installed microphone in time with the music in this mode.
f) Setting of the Microphone Sensitivity in Sound-to-light Operation
• Use the MENU (1) button to select SenS in the menu and push the ENTER (4) button.
• Select the desired microphone sensitivity with the UP (3) and DOWN (2) buttons.
0 Microphone sensitivity low
100 Microphone sensitivity high
• Press the ENTER button (4) to confirm your selection.
Set the microphone sensitivity so that the light effect changes in time with the music.

g) Setting the PAN-movement

• Use the MENU (1) button to select PInt in the menu and push the ENTER (4) button.
• Select the desired direction of the PAN movement with the UP (3) and DOWN (2) buttons.
no PAN-movement not inverted
YeS PAN-movement inverted
• Press the ENTER button (4) to confirm your selection.

h) Setting the TILT movement for bar 1

• Use the MENU (1) button to select tIn1 in the menu and push the ENTER (4) button.
• Select the desired direction of the TILT movement for bar 1 with the UP (3) and DOWN (2) buttons.
no TILT-movement not inverted
YeS TILT-movement inverted
• Press the ENTER button (4) to confirm your selection.
