STEP 6 (See Diagram 6)
1) Securely tighten all Nuts and Bolts previously installed.
2) Attach the Butterfly Base (#12) to the front of Rear Vertical Beam (#6). Attach the Butterfly Pulley
Bracket (#13) to the back of the Rear Vertical Beam. Align the holes. Secure them with two
M10 x 2 ¾" Carriage Bolts (#75), Ø ¾" Washers (#66), and M10 Aircraft Nuts (#86).
3) Attach the Right Butterfly (#11) to the hole on the Butterfly Base. Secure it with one Lock Ring (#56),
Ø 1 ½" Washer (#67), M6 x 1 ¼" Allen Bolt (#83), and M6 Aircraft Nut (#85).
4) Attach the Butterfly Arm Pad (#39) to the Right Butterfly. Secure it with two M8 x 2 ½" Allen Bolts
(#80) and Ø 5/8" Washers (#65).
5) Repeat Procedures C and D above to install the other side.
6) Insert two Swivel Pulley Brackets (#20) into the holes on the Butterfly Pulley Bracket (#13). Secure
each Swivel Pulley Bracket with one Ø ¾" Washer (#66) and M10 Aircraft Nut (#86). Do not over
tighten the Nuts. Make sure the Brackets are able to swivel.
