Satellite Antennas User Manual ver. 2.0

7.6 Operating the Free Way 1S Control Box

Appearance
Power S/W
TRACKING
ASTRA2S HOTBIRD AB3
VDO
ON
OFF
ASTRA1
ASTRA2N SIRIUS HISPSAT
SATELLITE
SEARCH SLEEP
SELECT
POWER
Satellite select button
Figure 7-3 Appearance of Free Way 1S Control Box
Functions of Control Box led
Tracking of
Power S/W
satellite
signal
TRACKING
ASTRA2S HOTBIRD AB3
VDO
ON
OFF
ASTRA1
ASTRA2N SIRIUS HISPSAT
SATELLITE
SEARCH SLEEP
SELECT
POWER
Searching the
Satellite selection button
Sleep mode
satellite signal
Figure 7-4 Functions of Free Way 1S Control Box led
47
