Satellite Antennas User Manual ver. 2.0
For the four outputs systems (Ocean Line 445 and Ocean Line 460) the diagram of
connections is described in Figure 1-3.
12~24 V DC
Control Box
(IDU)
Satellite
Receiver
H/L
H/H
V/H
Figure 1-3 Ocean Line 445/460 system diagram
Ocean Line 445 antenna
Ocean Line 460 antenna
V/L
Monitor TV
Switching
Box
Monitor
TV
