For the three outputs systems (Ocean Line 337, Ocean Line 345 and Ocean Line 360)
the diagram of connections is described in Figure 1-2.
Monitor TV
Satellite Receiver
12~24 V DC
Control Box
(IDU)
Figure 1-2
"SVR2„ "SVR3„
"CONTROL-BOX„
Ocean Line 337/345/360 system diagram
Satellite Antennas User Manual ver. 2.0
Ocean Line 337 antenna
Ocean Line 345 antenna
Ocean Line 360 antenna
Monitor TV
Satellite Receiver
Monitor TV
Satellite
Receiver
