2.1 Unpacking the unit

1. Open the box and removing the packing material
The following items are included in the packaging of the Ocean Line antennas.
Item
1
2
3
4
5
6
7
8
9
2. Lift dome out of box vertically. Do not turn box and "roll" out, or turn upside
down to remove.
Description
Ocean Line Antenna Unit
Control Box Unit
Power Cable (1,5 mt)
Coaxial Cable (15 mt)
Coaxial Cable short (1 mt)
Switching box (only for models ITA-082-000-445 / 460)
4x fixing nut with washer
Multilanguage User Manual
Warranty documentation

Table 2-1 Ocean Line package: parts included

Figure 2-1 Unpacking the unit
Satellite Antennas User Manual ver. 2.0
Quantity
1 pc
1 pc
1 pc
1 pc
1 pc
1 pc
1 set
1 pc
1 pc
