Satellite Antennas User Manual ver. 2.0
1.2 Antenna system overview
A complete satellite TV system, illustrated in the following figures, includes the Ocean
Line antenna connected to an IDU, one or more satellite receivers, each with a TV set.
For the one output system (Ocean Line 132) the diagram of connections is described in
Figure 1-1.
Ocean Line 132
Antenna
12~24 V DC
Satellite
Receiver
Control Box
(IDU)
Monitor
TV
Figure 1-1 Ocean Line 132 system diagram
