2.2 Preparing for the installation

1. Install Tools and Materials
The Ocean Line antenna systems are designed for simple installation and setup. However,
the following list of equipment or items should be available during installation of the
Ocean Line antennas.
Electric drill and drill bits
Socket wrench
Silicon sealant
Fastener suitable for specific application
2. Verification of the vessel's power supply
Confirm that the vessel's power supply is 12VDC~24VDC.
3. Verification of the satellite receiver and Control Box's attachment and the
electricity supply
Attach satellite receiver and Control Box in the interior of the vessel of the trunk
Connect the power of satellite receiver and Control Box
Once the power of Satellite Receiver and Control Box is verified, it confirms that
both Satellite Receiver and Control Box are working normally.
4. Procedure of the satellite's attachment and installation
Attach the satellite on the flat surface area of the vessel's roof.
Connect each end of the Coaxial antenna cable to the satellite's terminal and
the Control Box.
Connect the Control Box and the Satellite Receiver box together through the
coaxial cable.
Make sure that the satellite is working normally, once the power is supplied.
Warning: things to consider when installing the antenna:
Turn off the power when attaching or detaching the antenna.
Make sure that the attached satellite is fixed on the flat surface.
Ensure that all the cables are connected properly.
