Satellite Antennas User Manual ver. 2.0

6.1 Unpacking the unit

1. Open the box and removing the packing material
The following items are included in the packaging of the Free Way antennas.
Item
1
2
3
4
5
6
7
8
2. Lift dome out of box vertically. Do not turn box and "roll" out, or turn upside
down to remove.
Description
Free Way Antenna Unit
Control Box Unit
Power Cable (1,5 mt)
Coaxial Cable (10 mt)
Coaxial Cable short (1 mt)
4x install bracket
Multilanguage User Manual
Warranty documentation

Table 6-1 Free Way package: parts included

Figure 6-1

Unpacking the unit

Quantity
1 pc
1 pc
1 pc
1 pc
1 pc
1 set
1 pc
1 pc
