Satellite Antennas User Manual ver. 2.0
5.2 Antenna system overview
A complete satellite TV system, illustrated in Figure 5-1, includes the Free Way antenna
connected to an IDU, a satellite TV receiver, and a television set.
12~24 V DC
Control Box
(IDU)
Figure 5-1 Free Way 1S/1M system diagram
Free Way 1S Antenna
Free Way 1M Antenna
Monitor
TV
Satellite
Receiver
