5.1 Specifications

Antenna Type
Frequency Band
Frequency Range
Operativity
Dish Dimension
Antenna Weight
Antenna Gain
Minimum EIRP
Polarization
Type of Stabilization
Elevation Range
Azimuth Range
Tracking Rate
Temperate Range
Antenna Type
Frequency Band
Frequency Range
Operativity
Dish Dimension
Antenna Weight
Antenna Gain
Minimum EIRP
Polarization
Type of Stabilization
Elevation Range
Azimuth Range
Tracking Rate
Temperate Range
Power
Table 5-1 Free Way 1S specifications
Power
Table 5-2 Free Way 1M specifications
Satellite Antennas User Manual ver. 2.0
Parabola
Banda Ku
11,7 GHz – 12,75 GHz
stationary
390 x 700 mm
9,7 Kg
33 dBi
49 dBW
V/H o RHCP/LHCP
2-axis Step Motor
19° - 64°
unlimited
50° /sec
from -20° to 70°
12-24 V DC
Parabola
Banda Ku
11,7 GHz – 12,75 GHz
In-motion
390 x 700 mm
9,4 Kg
33 dBi
49 dBW
V/H o RHCP/LHCP
2-axis Step Motor
19° - 64°
unlimited
50° /sec
from -20° to 70°
12-24 V DC
