Press seal
HSD
2 ENPress seal
Table of Contents
1 Publishing Notes ...................................................... 15
2 Explanation of Symbols ........................................... 15
3 Tools and aids required ........................................... 15
4 Description .............................................................. 15
5 Preparing for installation ......................................... 15
6 Installation of the closed press seal for pipes to
be newly installed (D = 100 - 200 mm) from the
outside of the building ............................................ 16
7 In a retrofit situation, split the press seal for
pipes that have already been laid ............................ 16
8 Installing the closed press seal for pipes to be
newly installed (D = 100 - 200 mm) from the
inside of the building............................................... 16
9 Installation of the split press seal for already
installed pipes (D = 250 - 500 mm) from the
outside of the building ............................................ 16
10 Installation of the split press seal for already
installed pipes (D = 250 - 500 mm) from the
inside of the building............................................... 17
11 Mount the WRD sealing set ..................................... 17
12 Disassemble the press seal and the sealing set ........ 18
13 Affix FHRK seal ........................................................ 18

1 Publishing Notes

Copyright © 2022 by
Hauff-Technik GmbH & Co. KG
Department: Technical Editing
Robert-Bosch-Straße 9
89568 Hermaringen, GERMANY
Tel. +49 7322 1333-0
Fax +49 7322 1333-999
E-mail office@hauff-technik.de
Internet www.hauff-technik.de
Reproduction of this Installation instructions - even in
extracts - in the form of reprint, photocopy, on electronic
data media or using any other method requires our writ-
ten consent.
All rights reserved.
Subject to technical alterations at any time and without
prior announcement.
These installation instructions form part of the product.
Printed in the Federal Republic of Germany.

2 Explanation of Symbols

1 Work stages
► Effect/result of a work step
Reference numerals in drawings

Art. No.: 5090032098 Rev.: 01/2022-11-14

3 Tools and aids required

To install the Press seal HSD correctly, need the following
tools and aids in addition to the usual tools:
Tools
1 Torque wrench
1 Extension
1 Socket wrench insert SW5/SW6/SW8
Aids:
Lubricant
KRMTX cable cleaner
Vernier calliper
Cleaning cloth
To install the WRD correctly, you will need the following
tools and aids in addition to the usual tools:
1 Torque spanner
1 Extension
1 Internal hexagon socket SW3 or SW4 or SW 5 or
SW6 or
1 External hexagon socket SW6 or SW8 or SW10 or
SW13 or SW17 (see table 3)

4 Description

Description: HSD250 G 1x159 b40 (see Fig.: 1).
Legend for Fig.: 1
1 Elastomer segment HSD250 G 1x159 b40 (Grade:
EPDM or NBR)
2 Press plate U-profile
3 Allen screw
4 Media line (pipe)
Description: WRD150 (see Fig.: 2).
Legend for Fig.: 2
1 Press seal
2 Corrugated cable duct
3 Split ISO ring
- Ring clips (not visible in figure)

5 Preparing for installation

1 Clean the core drilling/liner and media line.
2 Level out any chips and/or blowholes that may be
present.
3 Check the diameter (D) tolerance of the core drill
hole/wall sleeve (D +2/-1 mm) and media line (d +1/-2
mm) as well as of the outer dimensions, i.e. drill di-
mensions of the pipe seal (see Fig. 2).
