Start-up

5.1

Please read this entire section before starting the pairing proce-

dure.

You can either pair the radiator thermostat directly with one or more

Homematic IP devices or add the device to the Homematic IP Access

Point (HmIP-HAP). After direct pairing, configuration must be done di-

rectly on the device. After pairing with the access point, configuration is

done via the Homematic IP app.

5.1.1

You can directly pair the Homematic IP Radiator Thermostat with

other Homematic IP Radiator Thermostats (HmIP-eTRV-CL or

HmIP-eTRV-B), the Homematic IP Window / Door Contact with

magnet (HmIP-SWDM (HmIP-SWDM-2) and/or the Homematic IP

Wall Thermostat (HmIP-WTH-B/HmIP- WTH-B-2).

Please make sure you maintain a distance of at least 50 cm between

the devices during pairing.

You can cancel the pairing procedure by briefly pressing the menu

button (D). This will be indicated by the device LED (D) lighting up

red.

To connect the device with another Homematic IP device, the pairing

mode of both devices must be activated. To do this, proceed as follows:

•

Open the battery compartments by pulling the cover (F) first

downwards and then forwards (see figure 3).

•

Pull the insulation strip out of the battery compartment.

•

Press and hold the menu button (D) until the configuration menu

opens.

•

Select "PAIR" using the plus and minus buttons (C + E).
