Installation
4.3

Installation of supporting wheel (optional)

Before installing accessories, make sure they are in a proper condition.
Mount the supporting wheel (41100041) on the paver
transport cart with the four screws. Tighten the screws.
The installation position is shown on the opposite.
4.4

Installation of special gripper and wider load support

Before installing accessories, make sure they are in a proper condition.
1. Dismount the gripper (12) by detaching the safety
splint and remove the bolt.
51100015
installation position
10 / 17 GB
