SPARE PARTS LIST
TOPCRAFT NR
DESCRIPTION
408730
SOCKET HEAD SCREW
408731
HOLD DOWN PLATE
408732
SAW MECHANISM COMPLETE
408733
SPRING
408734
NEEDLE ROLLER BEARING
408735
BIG GEAR + PIN
408736
LIFTING KNIFE PLATE
408737
GUIDE BLOCK
408738
BAFFLE COMPLETE
408740
LOCALIZING PIN
408741
PENDULAR BUTTON
408742
THIMBLE
408743
SPRING
408744
SWITCH DRAW BAR COMPLETE
408745
CIRCUIT PLATE
408746
SWITCH
408747
STATOR
800607
BEARING 607 Z
408748
CARBON BRUSH SET
408749
CARBON BRUSH HOLDER
408750
ROTOR
806000
BEARING 6000 Z
408751
SOCKET SCREW KEY
66
UK
REFNR
005
ALL PURPOSE SAW
006
007 T/M 10+12+15
THE NUMBERS IN THE FOLLOWING TEXT COR-
013
RESPOND WITH THE PICTURES AT PAGE 2
017
TECHNICAL SPECIFICATIONS
019 + 020
023
Voltage
Frequency
025
Power consumption
028 + 029 + 030
Number of revolutions, idle
035
Maximum saw thickness
Amount of travel
036
Weight
037
LpA (sound pressure)
LwA (sound capacity)
038
Vibration value
041 T/M 044
046
PRODUCT INFORMATION
047
Fig.A
050
1. Blade
2. Baseplate
051
3. Blade clamping screw
052
4. Switch
053 + 054
5. Speed control
6. Power cable
055
7. Adjusting screws baseplate length
056
8. Socket head wrench 4 mm (not shown)
_
SAFETY INSTRUCTIONS
The following pictograms are used in these instructions
for use:
instructions in this manual.
Carefully read this manual before using the machine.
Make sure that you know how the machine functions and
how to operate it. Maintain the machine in accordance
with the instructions to make sure it functions properly.
Keep this manual and the enclosed documentation with
the machine.
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Keep these instructions in a safe place!
Ferm
Ferm
English
| 230 V~
| 50 Hz
| 600 W
| 700 - 2300/min
| 150 mm
| 26 mm
| 3.5 kgs
| 90.4 dB(A)
| 103.4 dB(A)
| 6.3 m/s
2
Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance of the
Denotes risk of electric shock.
WHEN PUTTING THE MACHINE INTO OPE-
RATION:
1. Check if the switch is not in "ON" position before
you connect the mains plug to the mains voltage.
2. Always keep the power cable away from moving
parts of the tool.
SWITCH OFF THE MACHINE IMMEDIATELY
IN CASE OF
1. Malfunction in the mains plug, power cable or dama-
ging of cable.
2. Broken switch.
3. Smoke or stench of scorched insulation.
ELECTRICAL SAFETY
Always check if your mains voltage corresponds
with the value on the type plate.
The machine has been double-insulated in accor-
dance with EN 50144; therefore, an earth wire is
not necessary.
When replacing old cables or plugs
Throw away old cables or plugs immediately as soon as
new ones have replaced these. It is dangerous to put the
plug of a loose cable into the socket outlet.
When using extension cables
Only use an approved extension cable that is suitable for
the machine's power. The cores must have a diameter of
at least 1.5 mm
. When the extension cable is on a reel,
2
unroll the cable in its entirety.
3
