Alarmmeldungen

Number Message
40300 RS-485 communica-
tion alarm.
40301 RS-485 communica-
tion alarm.
40302 Active interface
(Modbus or Web-
GUI) communica-
tion timeout has
occured
40303 RS-485 communica-
tion alarm.
40304 No slave module
was found, please
check RS-485 con-
nection(s).
40305 Number of or combi-
nation of connected
slave types not sup-
ported.
40412 Software versions
of system control
and module(s) do
not match.
40413 Software versions
of system control
and module(s) do
not match.
40414 Software versions
of system control
and module(s) do
not match.
40415 Software versions
of system control
and module(s) do
not match.
40416 Software versions
of system control
and module(s) do
not match.
60090 Battery overvoltage.
60093 DC link overvoltage.
60102 DC link voltage too
low for operation.
60129 Battery voltage
under threshold set-
ting.
84
Fehlersuche
Effect Cause
No operation possi- Communication pro-
ble. blem on RS-485
bus.
No operation possi- Communication pro-
ble. blem on RS-485
bus.
No operation possi- Active interface
ble. (Modbus or Web-
GUI) communica-
tion timeout has
occured
No operation possi- Communication pro-
ble. blem on RS-485
bus.
System cannot No slave module
finish start-up proce- was found.
dure
System cannot Number of or combi-
finish start-up proce- nation of connected
dure slave types not sup-
ported.
System cannot Software versions
finish start-up proce- of system control
dure and module(s) do
not match.
System cannot Software versions
finish start-up proce- of system control
dure and module(s) do
not match.
System cannot Software versions
finish start-up proce- of system control
dure and module(s) do
not match.
System cannot Software versions
finish start-up proce- of system control
dure and module(s) do
not match.
System cannot Software versions
finish start-up proce- of system control
dure and module(s) do
not match.
No operation possi- Battery voltage too
ble. high.
No operation possi- DC link voltage too
ble. high.
No operation possi- DC link voltage too
ble. low.
No operation possi- Battery voltage
ble. under threshold set-
ting.
Action
Check RS-485 com-
munication.
Check RS-485 com-
munication.
Check active inter-
face (Modbus or
WebGUI) or disable
timeout.
Check RS-485 com-
munication.
Check RS-485 con-
nection(s) and
modules.
Check module confi-
guration. Only
homogeneous
modules are allo-
wed on one
RS-485 bus.
Software update
necessary.
Software update
necessary.
Software update
necessary.
Software update
necessary.
Software update
necessary.
Check battery vol-
tage.
Check DC link.
Check DC link pre-
charge.
Change battery
threshold setting.
2022-06-01 A67-0147-00.BKde-0
Detec-
ted by
System
control
System
control
System
control
System
control
System
control
System
control
System
control
System
control
System
control
System
control
System
control
DC-DC
module
DC-DC
module
DC-DC
module
DC-DC
module
01-00xx
