4. Acquiring CEPH Images (Optional)
Release the Exposure Switch when "Image capturing is completed" message appears
3.
on the screen.
54
During X-ray exposure, the status appears as follows.
▪
The LED light of the Exposure Switch turns yellow.
▪
The LED light on the top of the equipment turns yellow.
▪
An alert sound comes out to indicate that X-ray emission is
currently underway.
▪ On Console Software, the radiation mark turns yellow and "X-RAY"
changes to "X-RAY ON".
