1. Imaging System Overview
1.2

Control Panel

Membrane type
No.
1
2
3
4
4
Item
Column
UP/DOWN button
Horizontal Beam
UP/DOWN button
Temple Supports
OPEN/CLOSE
button
READY / RETURN
button
Description
Moves the Vertical Frame up or down.
(For adjusting the height of the Chinrest)
Aligns the Horizontal Beam in PANO mode.
Adjusts the Temple Supports for patient
positioning.
Indicates that imaging is ready after parameter
settings and the patient positioning are complete.
Initializes the positioning of the Rotating Unit.
