Technical data

determined in accordance with EN 624 or Truma test conditions
Trumavent TEB – 12 V
Power supply
12 V DC
Power consumption
0.3 to 1.0 A
Air flow rate
up to 135 m /h (with fan duct ÜR dia. 65 mm)
3
up to 142 m 3 /h (with fan duct VR dia. 72 mm)
EEC Type Approval
e1 03 2603
Trumavent TN – 230 V
Power supply
230 V ~ 50 Hz
Power consumption
0.5 A, 65 W
Air flow rate
up to 169 m 3 /h (with fan duct ÜR dia. 65 mm)
up to 182 m 3 /h (with fan duct VR dia. 72 mm)
The right to effect technical modifications is reserved!
8
Airmix (Accessories)
Circulating air operation via the heater
Slide valve (g) in upper position (red arrow).
Outside air from below
Slide valve (g) in lower position (blue arrow).
Mixture position
During the heating operation the slide valve (g) should only
be opened in downward direction by max. 1/4. The automatic
function of the fan may otherwise be troubled.
This comfort kit must not be used with heaters with
underfloor exhaust duct routing, the Trumatic S 55 T
heater or in combination with the Trumatic S 3002 K heater in
vehicles.
g
