RADIAL MITRE SAW
MSM1021
Thank you for buying this Ferm product.
By doing so you now have an excellent product,
delivered by one of Europe's leading suppliers.
All products delivered to you by Ferm are
manufactured according to the highest standards
of performance and safety. As part of our
philosophy we also provide an excellent customer
service, backed by our comprehensive warranty.
We hope you will enjoy using this product for
many years to come.
The numbers in the following text refer to the
pictures on page 2 - 3
Read the operating instructions carefully
before using this device. Familiarise
yourself with its functions and basic
operation. Service the device as per the
instructions to ensure that it always
functions properly. The operating
instructions and the accompanying
documentation must be kept in the
vicinity of the device.
Intended use
The electro tool is intended as a stationary
machine for making straight lengthways and
crossways cuts in wood. Horizontal mitre angles
of -45° to +45° as well as vertical bevel angles of
-45° are possible.
Contents

1. Machine information

2. Safety
3. Mounting accessories
4. Operation
5. Service & Maintenance
4
1. MACHINE INFORMATION
Technical specifications
Voltage
Capacity
Machine class
Revolutions, unloaded
Saw blade measurement
Angle for mitring
Angle for bevelling
Mitre saw maximum
sawing capacity:
Mitre 0º, Bevel 0º
Mitre 45º, Bevel 45º
Mitre 45º, Bevel 0º
Mitre 0º, Bevel 45º
Weight
Lpa (sound pressure)
Lwa (acoustic capacity)
Vibration level
Vibration level
The vibration emission level stated in this instruction
manual has been measured in accordance with a
standardised test given in EN 60745; it may be used
to compare one tool with another and as a
preliminary assessment of exposure to vibration
when using the tool for the applications mentioned.
- using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level.
- the times when the tool is switched off or when
it is running but not actually doing the job, may
significantly reduce the exposure level.
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns.
Features
Figs. 1, 2 and 3
1. On/off switch
2. Unlock button (On/off switch)
3. Unlock button (Blade protective cover)
4. Cover carbon brush
5. Lock-pin
6. Blade protective cover
7. Workpiece clamp
8. Guide fence
230 V~
1800 W
II (double insulated)
4800/min
255 x 16 x 2.8 mm
45º (left and right)
45º (only left)
75 x 300 mm
40 x 210 mm
75 x 210 mm
40 x 300 mm
21.0 kg
86.0 dB(A)
99.0 dB(A)
1.157 m/s
