Step 2: Following the steps of step 1, screw the front legs of the superstructure in accordance with
the diagram below.
Step 3: Install the back panel, as shown in the diagram below, using the hooks on the panel and inser-
ting it into the notches in the substructure frame.
Step 3.2 (Inlet option)
If an air intake is connected, the fireplace must then be placed on a dedicated base, first placing the
base as close as possible to where the unit will eventually be placed, leaving at least 0.5 m of free space
on either side of the unit for the free installation of the installation elements. The fireplace must be
placed on a structure on a base, e.g. on bricks, install the lower installation panels according to the
scheme in steps 4 and 5, and then remove the bases.
If this is not an option with an intake, proceed to the next step.
Step 4: In the next step, install the side panel according to the diagram below, inserting it using the
hooks in the notches in the substructure. Use the M5 screws in the diagram below to level the side
panels in the first case. The M5 bolt used to fix the hook should only be partially screwed in, leaving
room for the hook as shown in the diagram in steps 10 and 11.
Step 5: Then install the opposite side panel, similar to the instructions in Step 4.
Step 6 As shown in the diagram below, mount the front-bottom panel by inserting it using the hooks
in the notches in the side-bottom panels
Step 7: If you have not installed the inlet, this means that the unit is not yet installed on the substructu-
re, so in the next step place the unit on the substructure as shown in the diagram below.
Step 8: Mount the frame of the upper part of the superstructure as shown in the diagram below.
The diagram also shows that the side and front panels should extend 2 mm beyond the flange of the
fireplace frame.
Step 9: Install the top panel as shown in the diagram below by screwing it to the superstructure.
Step 10: Insert the side panel by inserting it into the notches in the substructure, using the hooks that
must be fastened after inserting it according to the diagram below. Before installation, screw the hooks
as shown in the diagram below and screw the hook screws to the top of the side panel by only partially
screwing it in (a few coils of thread) to leave room for the hook of the top panel.
Step 11. Similar to step 10, install the smaller side panel on the opposite side of the superstructure.
Step 12: Prepare the smaller front panel before installing it on the building structure, as shown in the
diagram below. Depending on the BSL or BSP version, screw in the appropriate hangers according to
the schemes below.
Step 13: Install the smaller front panel by sliding it into the notches in the side panel and substructure
as shown in the diagram below.
