Step 14: Prepare the two double side panels for installation as shown in the diagram below. Both pa-
nels will be in mirror image - the number of hooks at the bottom of both panels differs for the BSL and
BSP versions of the unit (see drawings below). The upper fastening screws should also be screwed only
partially (a few threaded coils), as was the case in the lower panels, so as to leave room for mounting
the upper frame, the supporting structure of the installation.
Step 15: Install side panels, top panels as shown in the diagram below.
Step 16. Prepare the double front panel, top panel as shown in the diagram below.
Step 17: Install the front cover plate as shown in the following figure by inserting it into the recesses
in the side panels using the hooks.
Step 18: Install the top frame of the superstructure as shown in the diagram below. Screw the frame to
each panel so that the whole structure is adequately stiffened.
Step 19: Install the top cover plate by screwing it to the previously installed frame of the substructure,
as shown in the diagram below.
SELECTION OF THE LOCATION OF THE DEVICE IN A DEDICATED BUILDING.
The choice of the place of installation of the device in a dedicated installation SIMPLE EASY BOX should
be dictated by the location of the chimney to which it will be connected. Dedicated installation gives
you several possibilities of chimney exit depending on the conditions created by the existing chimney
installation, or depending on the way of chimney exit will be finally selected.
CONNECT THE DEVICE TO THE CHIMNEY INSTALLATION.
The connection of the fireplace to the chimney installation should respect the local construction law
and the guidelines contained in the manual of the device itself, for which the SIMPLE BOX is only an
accessory. If there are no local guidelines for the installation of the appliance and its chimney installa-
tion, follow the instructions for the appliance and its connection included with the purchased fireplace.
MAINTENANCE
WARNING!!!!
All maintenance work should be carried out on a cooled down unit at least 12 hours after it has been
extinguished.
ATTENTION!!!!
Maintenance of the device may only be performed by a qualified service technician. It should also be
remembered that each heating appliance requires chimney sweeps in accordance with the guidelines
of the local building code, but at least once a year.
• The device should be periodically inspected at least once a year.
• Cleaning should take place regularly or as excess ash emerges.
• No changes may be made to the design of the unit.
• The device should not be cleaned with corrosive agents.
• When replacing individual components, use only original parts available from the manufacturer.
