G&D VisionXS-C-DP-UHR Installation Und Bedienung Seite 90

Installation
Establishing a connection to the user module
Transmission 1 Transmission 2 Transmission 2
Service Service
Plug a category 6 (or better) twisted pair cable, which is available as
Transmission 1:
accessory, into this interface. Connect the other end of the cable to the respective
interface of the user module or to one of the Dynamic Ports of a compatible matrix
(see page 4).
The activation of the
Use the
Transmission 2
part.
9 · G&D VisionXS-C-DP-UHR
Network Network Pwr Main Power Pwr Main Power
Transm. Redundancy feature
interface to establish a connection with a second counter-
Red. Power Red. Power
activates the
Transmission 2
interface.
