5. Installing the control unit
5.1
Indoor installation
1.
The control unit should be installed in a dry,
dust-free indoor location. To install it, drill two
8mm holes in the wall.
3.
The air compressor is positioned on top of the
control unit. The air compressor is supplied with
an L-angle and a hose connector. Both are con-
nected to the air outlet of the compressor.
5. Installing the control unit
The control unit is secured to the wall with the dow-
els and screws supplied.
The compressor's connector is plugged into the
socket from the control unit.
22 / 52
280 mm
2.
4.
