Instructions for installing a GRAF grey water system
Item no.
106686 grey2clean 380L/d
Platin 1500 L
106687 grey2clean 760L/d
Platin 3000 L
106688 grey2clean 1270L/d
Platin 5000 L
106689 grey2clean 1900L/d
Platin 7500 L
The points described in these instructions
must be observed in all cases. Failure to do
so shall invalidate the warranty. For any
additional items purchased through GRAF,
you will receive separate installation in-
structions in the transport packaging.
The components must be checked for any
damage before the system is transferred to
the pit.
You will receive separate instructions for
operation and maintenance of the system.
grey2clean
Contents
1. Installation conditions Platin tank
2. Dimensions
3. General information
4. Assembly
5. Installing the control unit
6. Connecting the air hoses
7. Setting the timer
8. Operation and maintenance
14 / 52
15
16
17
18
22
24
25
26
