4. Technische Daten / Abmessungen

Technische Daten
SE30 IP44 IP54 IP54 I
SE50 IP44 IP54 IP54 I
SEH50 IP44 IP54 IP54 I
SE56 IP44 IP54 IP54 I
SEH56 IP44 IP54 IP54 I
SE80 IP44 IP54 IP54 I
SEH80 IP44 IP54 IP54 I
Abmessungen
Typ Schachttiefe
885mm
SE30
885mm
SE50
SEH50 1036mm
928mm
SE56
1084mm
SEH56
1110mm
SE80
1110mm
SEH80
10
230/400V, 50Hz x 15kW
230/400V, 50Hz x 30kW
230/400V, 50Hz x 30kW
230/400V, 50Hz x 50kW
230/400V, 50Hz x 40kW
230/400V, 50Hz x 130kW
230/400V, 50Hz x 130kW
Schachtbreite
610mm
610mm
610mm
632mm
632mm
1400mm
1400mm
5x16qmm 580kg
5x16qmm 620kg
5x16qmm 630kg
5x16qmm 650kg
5x50qmm 710kg
5x16qmm 2.120kg
5x150qmm 2.120kg
Deckellagertiefe
330mm
474mm
474mm
563mm
563mm
700mm
700mm
Schachtbreite
50kg 400mm 50mm 40t
65kg 466mm 50mm 40t
65kg 466mm 50mm 40t
75kg 520mm 50mm 40t
75kg 520mm 50mm 40t
80kg 590mm 50mm 25t
80kg 590mm 50mm 25t
Deckellagerbreite
351mm
474mm
474mm
563mm
563mm
888mm
888mm
Schachttiefe
2 x DN40
2 x DN40
2 x DN40
2 x DN40
2 x DN40
2 x DN40
2 x DN40
