Manual - F-86
Kit Content
Before assembly, please inspect the contents of the kit. The photo below details the contents
of the kit with labels. If any parts are missing or defective, please identify the name or part
number (refer to the spare parts list near the end of the manual) then contact your local shop.

Model assembly

Main wing installation
1. Install the wing spar through the
main wing set pass-through as
shown.
Horizontal stabilizer installation
18
1. Connect the elevator servo connectors to the
servo extensions in the fuselage.Install the
horizontal stabilizer into the slot in the
fuselage.
2. Guide the servo wire into the
cockpit as shown, fix the main
wing to fuselage using the inclu-
ded plastic parts and screws, and
then connect the Y-harness wires
of CH1 and CH6.
