Manual - F-86
Vertical stabilizer installation

Landing gear installation

2. Insert the main landing gear assembly into the wing landing gear
slot and pivot 90 degrees to lock the landing gear in place.
Note: Main landing gear differs left & right.
www.modster.at
1. Connect the rudder servo connectors to the
servo extensions in the fuselage. Install the
vertical tail into the slot in the fuselage and
secure with the included screws.
1. Install the front landing gear into the slot at
the bottom of fuselage and fix with included
screw as shown.
19
