cecotec CONGA 2090 Bedienungsanleitung Seite 17

ENGLISH
Note:
The robot supports 2.4 G networks.
The Wi-Fi name and password cannot exceed 32 bits.
If the network configuration fails to connect, follow the below steps:
Press the power button for 5 seconds, the robot will enter sleeping mode and the Wi-Fi light
indicator will blink fast indicating connection error. Retry connecting the robot again following
the steps in the before section.
If the connection fails again, check if:
The robot is too far away from the router.
The Wi-Fi password is incorrect.
* This Conga model is compatible with Alexa and Google Assistant virtual assistants.
The following modes can be activated from the App:
Auto cleaning mode:
From standby mode, press the Auto mode button on the App and the robot will automatically
start operating. It will carry out a cleaning cycle in zigzag motion and then another one in Edge
mode. Once it has finished, it will return to the charging base.
It is the most commonly used cleaning mode and it is used to clean the the whole house's
surface. The robot vacuums the floor's dust automatically, in and organized and efficient way,
as it features memory and gyroscopic navigation supported by its camera.
Moreover, it changes direction when it finds obstacles throughout its route and it returns to
the charging base in a smart and direct way once the cleaning is over.
It includes Total Surface function, through which the robot cleans the whole surface and, if
necessary, returns to the charging base to recharge its battery and finish cleaning.
Edge mode
Select this mode from the App or the remote control, the robot will clean along the edges and
will return to the charging base through its smart technology once it has finished. If there is no
charging base, the robot will return to the starting point.
Random mode
Select this mode from the App, the robot will start cleaning randomly and then will return to
the charging base with its smart technology once it runs out of battery. The robot will not
create any map under this mode.
Twice mode
Select this mode from the App, the robot will carry out 2 whole cleaning cycles. When the cycle
is completed, it will return to the charging base with its smart technology.
Scrubbing mode
32
Select this mode from the App. When this mode is activated, the robot moves in a swaying
motion, simulating real scrubbing moves. It starts off cleaning in zig zag motion, then in Edge
mode, and finally returns to the charging base taking the straightest way and memorizing the
route. If it runs out of battery before finishing, it will recharge and the resume cleaning until
finished.
Use the App to enter the water intensity mode and select between low, medium or high.
Warnings:
Do not use the mop outdoors.
Remove the carpets before operating the robot under this mode.
During operation, control the water level on the Wet & dry tank. If it empties, fill it up again
before continuing scrubbing.
Take the Wet & dry tank and the mop out before charging the robot.
Note: In order to ensure perfect scrubbing, moisten the mop before starting scrubbing.
Manual mode
Use the direction buttons on the remote control or on the App to take the robot to the specific
points where you want it to clean.
Back home mode
This mode can be activated from the robot, the App or the remote control at any point of any
cleaning cycle.
Once it is activated, the robot will automatically return to the charging base.
Spiral mode
Select this mode for the robot to thoroughly clean a specific spot. It will start cleaning at a
specific point and will move in an outward spiral motion. Then, it will return to the starting
point in an inward spiral motion, and then will go to the charging base.
Smart Area mode
Once the home's map has been saved, select this mode for the robot to clean an area in zigzag
motion. The robot will clean the selected area and then will return directly to the charging
base. The robot will only clean the area selected on the map, therefore it will go to the point
and return to the base without vacuuming.
Spot mode
Select this mode if you want to clean thoroughly point in the map, making the most of the
robot's maximum power. The robot will clean the selected point in an outward spiral motion
and then will return to the starting point. Then, it will return directly to the charging base when
cleaning is completed. The robot will only clean the area selected on the map, therefore it will
go to the point and return to the base without vacuuming.
ENGLISH
33
