Spezifikationen
set {port_num}
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3} port
show
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
state set {OFF=0|ON=1|DISABLED=2}
linesensor {line_num} {BELOWMIN=0|
ABOVEMIN=1|ABOVEMAX=2|BELOWMAX=3}
state show
modbus
modbus enabled set <off=0/on=1>
modbus enabled show
modbus port set <ip_port>
modbus port show
mqtt
mqtt {broker_idx} enabled set {OFF=0|ON=1}
mqtt {broker_idx} enabled show
mqtt {broker_idx} server set "{dns_name}"
mqtt {broker_idx} server show
mqtt {broker_idx} tls enabled set {OFF=0|ON=1}
mqtt {broker_idx} tls enabled show
mqtt {broker_idx} port set {ip_port}
mqtt {broker_idx} port show
mqtt {broker_idx} user set "{username}"
mqtt {broker_idx} user show
mqtt {broker_idx} passw d set "{passw d}"
mqtt {broker_idx} passw d hash set "{passw d}" sets hashed passw d
mqtt {broker_idx} client set "{name}"
mqtt {broker_idx} client show
mqtt {broker_idx} qos set {QOS0=0|QOS1=1}
mqtt {broker_idx} qos show
mqtt {broker_idx} keepalive set {num_secs}
mqtt {broker_idx} keepalive show
mqtt {broker_idx} topic set "{name}"
mqtt {broker_idx} topic show
mqtt {broker_idx} console enabled set {OFF=0|
ON=1}
mqtt {broker_idx} console enabled show
mqtt {broker_idx} device data timer set
{num_secs}
mqtt {broker_idx} device data timer show
port
port {port_num} state set {OFF=0|ON=1}
port {port_num} state show
port all state set "{port_list}" {OFF=0|ON=1}
port all state {MODE0=0|MODE1=1|MODE2=2}
show
port all set {OFF=0|ON=1|OFF_REV=2|ON_REV=3} sw itch all ports on/off forw ard or reverse
port restart all set {REINIT=0|
OFF_REV_REINIT=1,OFF_REINIT=2}
port {port_num} reset
port {port_num} toggle
port {port_num} batch set {OFF=0|ON=1} w ait
{num_secs} {OFF=0|ON=1}
port {port_num} batch cancel
port {port_num} label set "{name}"
port {port_num} label show
port {port_num} initstate coldstart set {OFF=0|
ON=1|REMEMBER=2}
port {port_num} initstate coldstart show
77
Expert Power Control 8316
LEGACY - show s Port for Pow er Port Sw itching
actions
LEGACY - sets Port state for Pow er Port
Sw itching actions
LEGACY - show s Port state for Pow er Port
Sw itching actions
enters cmd group "modbus"
enables Modbus TCP support
show s if Modbus is enabled
sets Modbus TCP port
show s Modbus TCP port
enters cmd group "mqtt"
enable mqtt
show s if mqtt enabled
sets broker name
show s broker name
enable TLS
show s if TLS enabled
set broker TCP/IP port
show s broker TCP/IP port
sets username
show s username
sets passw ord
sets client name
show s client name
sets QoS level
show s QoS level
sets keep-alive time
show s keep-alive time
sets topic prefix
shw os topic prefix
permit console cmds
show s if console cmds allow ed
sets telemetry interval
show s telemetry interval
enters cmd group "port"
sets port to new state
show s port state
sets several ports in one cmd - e.g. port all state
set "1,3,5" 1
show s all port states in 3 different view modes
reinit coldstart sequence (optional first all off)
start reset sequence for port
toggles port
starts batch mode for port
cancels batch mode
sets port label name
show s port label name
sets port coldstart initialization
show s port coldstart initialization
L
L
L
4
