Gude Expert Power Control 8314 Anleitung Seite 62

Spezifikationen
epc8316TrapCtrl
epc8316TrapIPIndex
epc8316TrapAddr
epc8316portNumber
epc8316PortIndex
epc8316PortName
epc8316PortState
epc8316PortSw itchCount
epc8316PortStartupMode
epc8316PortStartupDelay
epc8316PortRepow erTime
epc8316PortResetDuration
epc8316ActivePow erChan
epc8316Pow erIndex
epc8316ChanStatus
epc8316AbsEnergyActive
epc8316Pow erActive
epc8316Current
epc8316Voltage
epc8316Frequency
epc8316Pow erFactor
epc8316Pangle
epc8316Pow erApparent
epc8316Pow erReactive
epc8316AbsEnergyReactive
epc8316AbsEnergyActiveResetta
ble
epc8316AbsEnergyReactiveReset
table
epc8316ResetTime
epc8316Forw EnergyActive
Expert Power Control 8316
.64.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.64.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.64.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.64.1.3.1.1.0
The number of Relay Ports
.64.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.64.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.64.1.3.1.2.1.3.x
current state a Relay Port
.64.1.3.1.2.1.4.x
The total number of sw itch actions ocurred on a Relay Port. Does not
count sw itch commands w hich w ill not sw itch the ralay state, so just
real relay sw itches are displayed here.
.64.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.64.1.3.1.2.1.6.x
Delay in sec for startup action
.64.1.3.1.2.1.7.x
Delay in sec for repow er port after sw itching off
.64.1.3.1.2.1.8.x
Delay in sec for turning Port on again after Reset action
.64.1.5.1.1.0
Number of suppported Pow er Channels.
.64.1.5.1.2.1.1.x
Index of Pow er Channel entries
.64.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.64.1.5.1.2.1.3.x
Absolute Active Energy counter.
.64.1.5.1.2.1.4.x
Active Pow er
.64.1.5.1.2.1.5.x
Actual Curent on Pow er Channel.
.64.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.64.1.5.1.2.1.7.x
Frequency of Pow er Channel
.64.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.64.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.64.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.64.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.64.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.64.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.64.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.64.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.64.1.5.1.2.1.16.x
Forw ard Active Energy counter.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Unsigned32 RO
Integer32 RO
Unsigned32 RO
Unsigned32 RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Unsigned32 RO
Unsigned32 RW
Unsigned32 RO
Unsigned32 RO
Unsigned32 RO
