Gude Expert Power Control 8314 Anleitung Seite 60

Spezifikationen
Name
epc8314TrapCtrl
epc8314TrapIPIndex
epc8314TrapAddr
epc8314portNumber
epc8314PortIndex
epc8314PortName
epc8314PortState
epc8314PortSw itchCount
epc8314PortStartupMode
epc8314PortStartupDelay
epc8314PortRepow erTime
epc8314PortResetDuration
epc8314ActivePow erChan
epc8314Pow erIndex
epc8314ChanStatus
epc8314AbsEnergyActive
epc8314Pow erActive
epc8314Current
epc8314Voltage
epc8314Frequency
epc8314Pow erFactor
epc8314Pangle
epc8314Pow erApparent
epc8314Pow erReactive
epc8314AbsEnergyReactive
epc8314AbsEnergyActiveResetta
ble
epc8314AbsEnergyReactiveReset
table
epc8314ResetTime
Expert Power Control 8316
OID
Description
.97.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.97.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.97.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.97.1.3.1.1.0
The number of Relay Ports
.97.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.97.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.97.1.3.1.2.1.3.x
current state a Relay Port
.97.1.3.1.2.1.4.x
The total number of sw itch actions ocurred on a Relay Port. Does not
count sw itch commands w hich w ill not sw itch the ralay state, so just
real relay sw itches are displayed here.
.97.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.97.1.3.1.2.1.6.x
Delay in sec for startup action
.97.1.3.1.2.1.7.x
Delay in sec for repow er port after sw itching off
.97.1.3.1.2.1.8.x
Delay in sec for turning Port on again after Reset action
.97.1.5.1.1.0
Number of suppported Pow er Channels.
.97.1.5.1.2.1.1.x
Index of Pow er Channel entries
.97.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.97.1.5.1.2.1.3.x
Absolute Active Energy counter.
.97.1.5.1.2.1.4.x
Active Pow er
.97.1.5.1.2.1.5.x
Actual Curent on Pow er Channel.
.97.1.5.1.2.1.6.x
Actual Voltage on Pow er Channel
.97.1.5.1.2.1.7.x
Frequency of Pow er Channel
.97.1.5.1.2.1.8.x
Pow er Factor of Channel betw een -1.0 and 1.00
.97.1.5.1.2.1.9.x
Phase Angle betw een Voltage and L Line Current betw een -180.0 and
180.0
.97.1.5.1.2.1.10.x
L Line Mean Apparent Pow er
.97.1.5.1.2.1.11.x
L Line Mean Reactive Pow er
.97.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.97.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all
resettable counter.
.97.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.97.1.5.1.2.1.15.x
Type Acc.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Unsigned32 RO
Integer32 RO
Unsigned32 RO
Unsigned32 RO
Unsigned32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Unsigned32 RO
Unsigned32 RW
Unsigned32 RO
Unsigned32 RO
© 2022 GUDE Systems GmbH
60
