Introduction

The following icons / symbols are used in this instruction manual:
Cordless drill PABS 10.8 A2
Introduction
Q
Before you use it for the first time, it is es-
sential that you make yourself fully familiar
with the functions of the appliance and
find out how to correctly handle electrically powered
tools. Read the following directions for use as well as
the safety instructions. Keep these instructions. When
handing the device on to a third party, hand these
instructions on, too.

Intended purpose

Q
This appliance is designed for drilling and screwing
into wood, plastic and metal. Use the appliance only
as described and only for the purposes indicated.
Any other uses, and modifications to the appliance,
are deemed to be improper usage and may result
in serious physical injury. The manufacturer accepts
no responsibility for damage(s) resulting from
improper usage. The appliance is not intended for
commercial use.

Equipment Components

Q
Gear selector switch
1
Button for rechargeable battery LED
2
Rechargeable battery LED (status indication)
3
6 GB
Downloaded from www.Manualslib.com
Read instruction manual!
Observe caution and safety notes!
Caution – electric shock!
Danger to life!
Explosive material!
manuals search engine
Keep children away from electrical
power tools!
for indoor use only!
Check that the device, mains lead
and plug are in good condition!
Bit garage
4
Direction of rotation switch/lock
5
On / Off switch
6
Soft-grip
7
Battery pack
8
Battery unlocking button
9
Light
10
Torque control / drill step
11
Quick-action drill chuck
12
Status LED red
13
Battery charge status indicator green
14
fast charger
15

Items supplied

Q
1 Cordless drill PABS 10.8 A2
1 Rechargeable battery pack PABS 10.8 A2-1
1 fast charger PABS 10.8 A2-2
2 Bits in bit garage (S2 PZ1, S2 PZ2)
1 Carry case
1 Directions for use

Technical Data

Q
Cordless Drill PABS 10.8 A2:
nominal voltage: 10.8 V
Idle-running speed: 1st gear: 0–400 min
2nd gear: 0–1300 min
Drill chuck
clamping range: max. 10 mm
-1
-1
