EA01307D
8.3

Removing the battery

1 →
T20
2.
‣
Loosen the Torx screws, open the
cover.
3 →
‣
Release the battery cables.
8.4

Installing the battery

Installation is carried out in reverse order as described in Section 8.3 →  14.
8.5

Final steps

8.5.1 Switching on the power of the transmitter housing, compact version
1. Device powered by mains power supply: connect the device to the mains.
14
2 →
1.
1.
‣
Loosen the Torx screws, remove
the battery compartment cover.
T20
2.
4
‣
Remove the batteries
