Operation; Stand Alone Operation; Dmx-Controlled Operation; Dmx-Protocol - EuroLite TC-200 Bedienungsanleitung

The occupation of the connection-cables is as follows:
Cable Pin International
Brown Live L
Blue Neutral N
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
Lighting effects must not be connected to dimming-packs.

OPERATION

After you connected the effect to the mains, the TC-200/TC-300 starts running. During the Reset, the motors
are trimmed and the device is ready for use within approximately 20 seconds.

Stand Alone operation

In the Stand Alone mode, the TC-200/TC-300 can be used without controller. You can do without a controller
as the TC-200/TC-300 features a built-in microphone, which provides automatic sound control.
Disconnect the TC-200/TC-300 from the controller and set all DIP-switches to Off.
The lamp is automatically ignited as soon as the condensor microphone receives music signals.
Call up the internal program
In order to call up the internal program, set DIP-switches No. 9 and 10 to On.
Master/Slave-operation
Connect the master and slave-devices as desribed above and set the DIP-switches accordingly.
Please note: If you wish to change from one operating mode into another, you either have to switch off the
lamp/activate Blackout-mode or unplug the projector from the mains and plug it again.

DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.

DMX-protocol

DMX-value Feature
0-16 Offen/weiß
17-33 Red
34-55 Yellow
51-67 Magenta
68-84 Green
85-101 Orange
102-118 Blue
119-135 Pink
136-255 Rainbow effect with increasing speed
Control channel 2 - Dimmer intensity
DMX-value Feature
0-255 Gradual adjustment of the dimmer intensity from 0 to 100 %
