Height Setting Model Mt200V - Animo M-LINE M200 Betriebsanleitung

1. Connect the water connection hose (supplied) to the swivel nut on the back of the
appliance and to a manually-operated aeration tap. NB! Only cold water.
Open the water tap and check the connection for leaks.
2. Slide an empty basket filter (3) into the appliance and place an empty jug (with lid)
under it. NB! For the MT200 model, open the lid of the thermos jug with pump and
leave the riser tube in the jug. Adjust the height of the MT200(v) model before
positioning it, see 3.2.6.
3. Check if all on/off switches (1 + 2, if present) are at the 0 position.
4. Put the plug in the socket.
5. Switch on the appliance by setting the on/off switch (1) to position I. The indicator
lights (5.2) and (5.3) lights will light up and you will hear a signal. The display (5.1)
will then show the preset standard number of cups.
6. Press the start/stop button and the internal reservoir will fill up. Press the start/stop
button again if water has not started flowing after three minutes.
7. The green indicator light (5.3) will now light up until the appliance has finished
making the coffee.
8. Once the appliance has completed the process a signal will sound after about 1.5
minutes and the green indicator light (5.3) will go out.
9. Follow the above procedure again for the other coffee making section if the model
has a double coffee making system (M202).
10. Once the jug has been emptied, the appliance is ready for use.

3.2.6 Height setting model MT200v

The MT200v model is in height adjustable. Follow the steps below to optimally set the
appliance to the height of the thermos flask being used.
1. Slide the basket filter (1) into the appliance.
2. Grasp the top part of the appliance and turn the
adjustment button (2) a half-turn anti clockwise.
3. Lift the top part of the appliance upwards.
4. Place the thermos jug you intend to use at the
base of the appliance.
5. Now slowly allow the top section to go down until
the marking line (3) on the column is level with
the top side of the thermos jug. (This column
height adjustment must be done with the top
open if the appliance is used in combination with
a thermos jug with a pump).
6. Tighten the adjustment button (clockwise).
7. After repositioning, check if the thermos jug
properly presses in the jug detector
handle (4) (the green indicator light (5.3) must
not blink when a coffee making process begins).
GB
4
29
M-LINE
5.3
1
3
2
2015/02 Rev. 4.0
