Selection button (5.4); The selection button is used to reduce the amount of
coffee set in the display. When the lowest value is reached the display returns
to the maximum amount.
BOILER
Start/stop button (5.5); The start/stop button is used to start and
(emergency) stop the coffee making process.

2. TECHNICAL DETAILS

Model
Article number
Buffer stock coffee
Hourly coffee capacity
Jug filling time
coffee amount
Supply voltage
Frequency
Total output
Filter paper
Min. water pressure
Max. water pressure
Dimensions
Empty weight
Transport dim. (lxwxh)
Transport weight
All technical details are subject to change

3. INSTALLATION

3.1

Unpacking

The machine has been carefully packed to prevent damage being caused to your new
coffee maker. Remove the packing carefully without using sharp objects. Check if the
appliance is complete. The appliance is delivered with the following accessories:
Glass jug
Basket filter
Filter paper (25 pcs.)
Coffee measuring cup
Funnel
Water connection hose
Coffee fur remover
Scale remover
Manual
Please contact your dealer if any parts are missing or damaged.
GB
BOILER
M200 M202
10551 10562
3.6 l./ 28 cups 7.2 l. / 56 cups
18 l./144 cups 36 l./288 cups
approx. 6 min. approx. 8 min.
1 -3 l. 1 -3 l
220-240V~ 220-240V~
50-60Cy 50-60Cy
2250W 3500W
90/250 90/250
0.2 MPa (2 bar) 0.2 MPa (2 bar)
1 MPa (10 bar) 1 MPa (10 bar)
See fig. 1 See fig. 2
7,5 kg. 13,6 kg.
600x275x530 mm 600x490x540 mm
9,6 kg. 17,9 kg.
M200
2
1
1
1
1
1
1
1
1
MT200
10572
-
18 l./144 cups
approx. 7,5 min./2.2 l. approx. 7,5 min./2.2 l.
1 -3 l.
220-240V~
50-60Cy
2100W
90/250
0.2 MPa (2 bar)
1 MPa (10 bar)
See fig. 3
7 kg.
440x270x670 mm
9 kg.
M202 MT200
4 -
2 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
27
M-LINE
MT202v
10587
-
18 l./144 cups
1 -3 l.
220-240V~
50-60Cy
2100W
90/250
0.2 MPa (2 bar)
1 MPa (10 bar)
See fig. 4
9 kg.
440x270x670 mm
11 kg.
MT200v
-
1
1
1
1
1
1
1
1
