ENGLISH
A. WARNINGS FOR CORRECT USE
Read all the instructions and warnings carefully before using
GET Second Injector Kit. Failure to read and/or observe the
instructions and warnings can lead to incorrect use of the
device or its malfunction, resulting in product damage and
personal injuries.
GET SECOND INJECTOR KIT IS INTENDED ONLY AND
EXCLUSIVELY FOR RACING USE.

GENERAL WARNINGS

1. Follow the instructions described in this manual to prevent
vehicle damages.
2. Do not modify or replace the material supplied by GET.
3. Always make sure that no installed part can interfere with
the hot parts of the engine, the steering components or with
the rider.
4. The product is not a toy. Keep it out of the reach of children
and/or animals as it contains small sized components that
could be swallowed.
5. Do not use the product for purposes other than those
specified in these instructions.
6. Do not use high pressure washers on the product.
SPECIFIC WARNINGS
1. Always make sure that GET Second Injector Kit is properly
installed and functional prior to use.
2. Never expose the device to temperatures above 70°C/158°F.
3. Install it when the engine is cold.
4. If the bike does not start or the engine is irregular, be sure
that both GET ECU kit and GET Second Injector Kit chosen are
compatible with your bike model and year; verify that both the
ECU and the second injector kit are connected properly and
always perform a TPS calibration.
EN 2
5. GET Second Injector kit works only with GET ECU which are
"second injector ready" (with the specific "INJ 2" connector).
The GET 2nd Injector Kit can be supplied:
Included in GET Pro Factory Kit: GET ECU is plug&play and
it is ready to work after the second injector is installed. The
ECU comes with two pre-installed maps:
- Map 1: activate only the OE injector
- Map 2: activate the OE injector and GET 2nd injector
As accessory to a compatible GET ECU previously installed:
in this case before installing the 2nd Injector Kit it is
necessary to install the specifically developed power map
on the ECU. Download it for free from www.athena.eu on
the specific product page and install it using GET Maya
programming software (sold separately). Otherwise, ask
for assistance to your GET dealership.
B. PRODUCT LAYOUT
Screws
and washers
Fuel rail
Second
Injector
2nd Injector
O-Ring
2nd injector
support
bracket
GET fuel hose
3-way
fitting
Hose
clamps
Second
Injector
harness
2nd injector
fixing
bracket
3 EN
