Pinbelegung der Centronics Schnittstelle 36 polig
B-4
Pin
Belegung
18
Not connected, optional + 5V
19
Signal Ground
20
Signal Ground
21
Signal Ground
22
Signal Ground
23
Signal Ground
24
Signal Ground
25
Signal Ground
26
Signal Ground
27
Signal Ground
28
Signal Ground
29
Signal Ground
30
Signal Ground
31
nInit
32
nFault
33
Signal Ground
34
Signal Ground
35
Not connected
36
nSelectIn
Ein- oder Ausgang
-, optional external power supply from printer
-
-
-
-
-
-
-
-
-
-
-
-
OUT
IN
-
-
-
OUT
