4 Installing the 2100 Bioanalyzer System
Installing the 2100 Bioanalyzer System
3 Open the lid of the 2100 Bioanalyzer instrument and slide the electrode
4 Connect one end of the serial cable to the RS-232 port located at the rear of
cartridge into the lid and move the lever into a flat (closed) position.
Lid
Electrode cartridge
Electrodes
Chip selector
(not present in G2939B)
Heater plate
Focusing lens
the instrument.
RS-232 port
Power input socket
Power switch
