CONTROLLER INSTALATION
Install the controller in dry room, where it is not directly exposed to strong electromagne-
tic fields. Press the controller directly onto the mixing valve. Disassembling or opening
of the controller is not needed and not allowed.

INSTALLATION ONTO MIXING VALVE

Example of installation onto 3 way mixing valve.
Example of installation onto 4 way mixing valve.
The mixing valve needs to be turned in the middle position.
J5060403 v1.2

INSTALLATION MANUAL

37
1a 1a
1b
