‚STORAGE' CONTROL OF LITHIUM BATTERY
This function is for charging/discharging batteries which are not used at once. This
program is designed for charging or discharging of batteries of specific original
state. They are classified by types: 3.75V Lilon,
3.85V LiPo and 3.3V LiFe. The program will begin to discharge if the original state
of battery exceeds the voltage level of storage.
- +
DEC. INC. DEC. INC.
Batt type Start
Stop Enter
Start
Enter
Elapsed Supplied
Number
time capacity
of
Charge
cells
or discharge
current
14
At this screen, you can set up the current and volt-
age of the battery pack. Charging and discharging
will make the batteries come to the voltage level of
storage state.
- +
This screen displays the number of cells you set
>3 seconds
up and the processor detects. R=Number of cells
detected by charger. S=Number of cells set by you
at the previous screen.
If both numbers are identical you can start charging
process by press START/ENTER button. If not,
press BATT TYPE/STOP button to go back to pre-
vious screen to recheck the number of cells of the
battery pack before going ahead.
This screen shows the real-time status charging.
Press BATT TYPE/STOP button
once to stop the charge process.
Current
voltage
battery
