CHARGING OF LITHIUM BATTERY
This charging mode is for charging LiPo/LiFe/LiIon battery in normal mode.
Note: We recommend charging lithium batteries with a balance lead in the balance
mode only.
-
+
DEC. INC.
Batt type Start
Stop Enter
Start
Enter
Number
Battery
Charging
of
voltage
time
cells
Charging
current
12
The left side of the first line shows the type of
battery you choose. The value on the left of the
second line of the charger is current the user sets.
After setting the current and voltage, press the
-
+
START/ENTER button for more than 3 seconds to
DEC. INC.
start the process.
>3 seconds
This displays the number of cells you set up and
the processor detects.
R=Number of cells detected by charger. S=Num-
ber of cells set by you at the previous screen.
If both numbers are identical you can start
charging process. If not, press button to go back to
previous screen to recheck the number of cells of
the battery pack before going ahead.
This screen shows the real-time status during
charge process. Press button once to stop the
charge process.
Charged
capacity
