side of the worm with the plastic end has to face the worm housing when putting it
inside the worm housing. If the worm is correctly assembled when the plastic end of
the worm stands a few millimetres out of the worm housing. Take the adaptor disc.
The small end with the recess has to face the worm when attaching. If necessary turn
the adaptor disc a little bit until the arresting pin of the worm housing locks precisely
into the corresponding recesses of the adaptor disc.
IMPORTANT:
properly inside of the worm housing. Turn the worm a little bit to make it fit inside but do
not use force. If mounted correctly the adaptor disc is aligned with the front of the worm
housing and the axis of the worm stands out 2 mm of the grinding disc.
Place the cookie attachment on the worm housing. The flat end has to face the worm
housing when attaching. Fit the closure ring over the cookie attachment. Firmly screw the
closing ring on the worm housing and tighten by hand.
ATTENTION: Do not use any tools, for tightening the screw and pay attention not to
cant the screw. If the screw cants the screw thread gets damaged. If the screw does not
turn easily put some sunflower oil (or other edible oil) on the screw.
2. Firmly secure the worm housing in the opening for the drive shaft. The small end of
the worm housing has to face the mincer (picture N). Incline the worm housing a little
bit to the right, when assembling it. When the worm housing is fitted all the way into
the opening of the drive shaft the release button sinks into the motor housing. Turn the
worm housing counter clockwise until the shaft is facing upright and is locked into
place.
Note:
When the worm housing is securely attached you can hear a click sound and the
release button comes out of the recess again.
3. Press the feed pan onto the worm housing (picture O). Slide the cookie former
into the cookie attachment and choose the desired cookie shape. Ensure the
handle is facing away from the attachment when sliding it in otherwise you can-
not use the cookie shape that is the closest to the handle.
4. Place the pusher into the opening of the feed chute (picture P).
The appliance is ready for operation.

MINCING MEAT

The mincer operates absolutely dependently and clean. If any problems should occur
while operating act upon instructions ›Trouble shooting‹.
50
All manuals and user guides at all-guides.com
If the tools overlap the edges of the worm housing the worm is not placed
