Displays
Operating display
Table 5-1
Fault display
Table 5-2
5-2
All manuals and user guides at all-guides.com
08.2000
LED Status
Flashing Fault-free net data transfer via SIMOLINK
Green
Flashing SLB operating
Red
Yellow Flashing Data exchange with basic unit is okay
SLB operating display
LED Status
No net data exchange possible via SIMOLINK;
Green off/on
bus cable is not connected or is defective
Red off Voltage supply for SLB cut off;
replace SLB or basic unit
Yellow off/on No data exchange with the basic unit;
bus cable is not connected or is defective;
replace SLB or basic unit
SLB fault display
Diagnostic information
Diagnostic information
