SLB - SIMOLINK Board
5

Displays

Three LED displays are provided on the front side of the SLB optional board
which give information on the current operating status. These are as follows:
♦ SIMOLINK operating (green)
♦ Board operating (red)
♦ Data exchange with the basic unit (yellow)
Fig. 5-1 SLB displays
Siemens AG 6SE7087-6NX84-0FJ0
SIMOVERT MASTERDRIVES
All manuals and user guides at all-guides.com
08.2000
System connector
Fixing screw
Operating Instructions
Displays
Fixing screw
LED (green)
LED (red)
LED (yellow)
X470 external 24 V voltage supply
SIMOLINK output (light gray)
SIMOLINK input (dark gray)
5-1
